9203610000 - Versatile Cable Stripping Tool for 0.75-4mm² Insulated Conductors
9203610000 - Versatile Cable Stripping Tool for 0.75-4mm² Insulated Conductors
SKU: SKU: 9203610000 Download PDF
- 9203610000 - Versatile Cable Stripping Tool for 0.75-4mm² Insulated Conductors
- 9203610000 - Versatile Cable Stripping Tool for 0.75-4mm² Insulated Conductors
Couldn't load pickup availability
Description:
Introducing a specialized tool for stripping and cutting cables, perfect for those with zero-halogen insulation This device is compatible with conductor sizes between 075 and 40 mm², making it highly versatile It efficiently handles both flexible and solid conductors that have PVC insulation The tool boasts a cutting capacity of up to 6 mm² for fine-stranded conductors and 25 mm² for solid ones, making it an essential piece for various cable stripping applications.
Features and Benefits:
•Designed for zero-halogen insulation cables.
•Can cut cables with a minimum conductor cross-section of 0.75 mm².
•Maximum stripping length of 2 mm.
•Can accommodate a stripping range up to 10 AWG.
Specifications:
| Depth | 40 mm |
| Height | 85 mm |
| Width | 250 mm |
| Max. cutting capacity, fine-strand | 6 mm² |
| Max. cutting capacity, ribbon | 10.2 mm x 4 mm |
| Max. cutting capacity, solid | 2.5 mm² |
| Stripping length, min. | 2 mm |
| Conductor cross-section, max. | 4 mm² |
| Conductor cross-section, min. | 0.75 mm² |
| Net weight | 519.28 g |
| RoHS Compliance Status | Not affected |
| REACH SVHC | Lead 7439-92-1 |
