Home / F-BCM3-12P-1000 Fiber bulk cable – 12 strand multimode OM3 – plenum & indoor/outdoor rated – micro distribution style – 1000ft spool – black
1 1

F-BCM3-12P-1000 Fiber bulk cable – 12 strand multimode OM3 – plenum & indoor/outdoor rated – micro distribution style – 1000ft spool – black

F-BCM3-12P-1000 Fiber bulk cable – 12 strand multimode OM3 – plenum & indoor/outdoor rated – micro distribution style – 1000ft spool – black

SKU: F-BCM3-12P-1000 Download PDF

FT
Enter footage in the box - Cut to one length. Min 1 ft - Max 10000 ft.
Now $81,650.00 /FT
BEFORE   Now $81,650.00 /FT
Sold out
Web pricing policyShipping calculated at checkout.
IN STOCK
Shipping Available
Free shipping on orders above $1000.* Only on standard purchases of cables and wires.
View full details
Product Information Resources Reviews
Product Information

*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color

Resources

Description:

Fiber bulk cable – 12 strand multimode OM3 – plenum & indoor/outdoor rated – micro distribution style – 1000ft spool – black Duplex Riser Multimode OM3 Fiber Cable is constructed with two internal tight buffers, internal aramid yarn, and one outer riser-rated PVC jacket in distribution format The fiber cable is designed for indoor applications and features Corning ClearCurve fiber.

Features and Benefits:

    •Multimode OM3 fiber.

    •Twelve strand distribution format.

    •Black color.

    •Plenum-rated for indoor and outdoor applications.

    •Water-resistant construction for installation in conduit.

    •Tight buffered construction.

    •3.5 lbs stripping force.

    •Corning ClearCurve fiber.

Specifications:

 Fiber Count 12 strands
 Outer Jacket Flame retardant PVC, Black color
 Strength Member Aramid Yarn
 Internal Jacket Tight buffer, flame retardant PVC
 Outer Jacket Size 5.8mm
 Fiber Type Multimode OM3
 Fiber Core Size 50µm
 Fiber Make Corning 50/125 ClearCurve
 Wavelength 850 / 1300nm
 Maximum Attenuation 3.5dB @ 1.5km
 Bandwidth (High Performance EMB) 2000MHz @ 850nm
 Network Link Length (10Gb/s) 300m
 Minimum Bend Radius 8.7mm
 Storage Temperature -40°C to +70°C
 Operating Temperature -0°C to +70°C
 Ratings NFPA262 (flame rating), UL, RoHS
