Belden 27601A 18 AWG 8 Conductor 7x26 Stranding Bare Copper 600V Multi-Conductor Cable

Description:

UL Type TC (1277) PVC-Nylon/PVC, 8 Conductor 18 AWG (7x26) Bare Copper, PVC-NYL Insulation E2 Color Code, Black PVC Outer Jacket, 600V TC 150V NPLF 90C Dry/Wet SUN RES DIR BUR.

Insulation:

• Material: PVC/Nylon - Polyvinyl Chloride + Nylon
• Nom. Thickness: 0.022 in (0.56 mm)
• Nom. Insulation Diameter: 0.088 in (2.2 mm)

Outer Jacket:

• Material: PVC - Polyvinyl Chloride
• Nom. Thickness: 0.047 in (1.2 mm)
• Nom. Diameter: 0.385 in
• Overall Cable Diameter (Nominal): 0.385 in

Standards:

• UL Temperature: 90°C Dry, 75°C Wet
• Voltage Rating: 600 V (TC), 150 V (NPLF)
• Operating Temperature: Wet: -30°C to 75°C, Dry: -30°C to 90°C

Applications:

• Power and Control Applications up to 600V; Class 1 Division 2 Hazardous Locations; Recommended Cable Gland Belden BTC075A0551RA
