9457614500 - 45m Unshielded 5-Pole Sensor/Actuator Cable, PUR Sheath

9457614500 - 45m Unshielded 5-Pole Sensor/Actuator Cable, PUR Sheath

SKU: SKU: 9457614500

Select a Variant:
  • 9457614500 - 45m Unshielded 5-Pole Sensor/Actuator Cable, PUR Sheath
Qty:
Regular price Now $63.82   Web pricing policy
Regular price BEFORE   $0.00 Sale price Now $63.82 Web pricing policy
Sold out
Shipping calculated at checkout.
IN STOCK
Shipping Available
Free shipping on orders above $1000. *Wires and cables only.
View full details
Product Information

Description:

Introducing the SAIL-M12G-5-45U, a specialized sensor/actuator line featuring a straight pin configuration with five poles This impressive 45-meter cable is unshielded and does not come with a connector on one end, ensuring versatility for various applications Crafted from halogen-free PUR material, it promotes safety and durability in any setting Ideal for your connectivity needs, this cable supports reliable signal transmission without the hassle of an LED indicator.

Features and Benefits:

    •Compliant with RoHS regulations.

    •Hydrolysis and microbe resistant.

    •LABS-free.

    •Suitable for cable carriers.

Specifications:

 Acceleration 5 m/s²
 Bending cycles 12 Mio
 Bending radius, min., moving 10 x cable diameter
 Bending radius, min., stationary 5 x cable diameter
 Cable length 45 m
 Core cross-section 0.34 mm²
 Number of poles 5
 Outer diameter 4.7 mm ± 0.15 mm
 Nominal current 4 A
 Nominal voltage 60 V
 Protection degree IP65, IP66, IP67, IP68, IP69 when screwed in
 Temperature range, moving -25...60 °C
 Temperature range, stationary -50...80 °C
 Threaded ring material Diecast zinc
