9457611500 - 15m M12 5-Pole Sensor/Actuator Cable, PUR Sheath

9457611500 - 15m M12 5-Pole Sensor/Actuator Cable, PUR Sheath

SKU: SKU: 9457611500

Select a Variant:
  • 9457611500 - 15m M12 5-Pole Sensor/Actuator Cable, PUR Sheath
Qty:
Regular price Now $25.45   Web pricing policy
Regular price BEFORE   $0.00 Sale price Now $25.45 Web pricing policy
Sold out
Shipping calculated at checkout.
IN STOCK
Shipping Available
Free shipping on orders above $1000. *Wires and cables only.
View full details
Product Information

Description:

Introducing a versatile sensor/actuator cable, measuring 15 meters long and featuring a straightforward design One end of the cable is connector-free, while the other boasts an M12 connection with five poles Crafted from halogen-free PUR material, this straight cable is designed without shielding or LED indicators, ensuring reliable performance for various applications Perfect for scenarios requiring durable and efficient connectivity.

Features and Benefits:

    •Sensor/actuator line with one end without connector.

    •Straight pin configuration.

    •Halogen-free sheath.

    •Durable sheath material made from PUR.

    •Resistance to oils and microbial attack.

    •Configured for cable carriers.

    •High bending cycle capability.

Specifications:

 Cable length 15 m
 Core cross-section 0.34 mm²
 Number of poles 5
 Number of wires 5
 Outside diameter 4.7 mm ± 0.15 mm
 Nominal current 4 A
 Nominal voltage 60 V
 Temperature range, moving -25...60 °C
 Temperature range, stationary -50...80 °C
 Bending radius, min., moving 10 x cable diameter
 Bending radius, min., stationary 5 x cable diameter
 Protection degree IP65, IP66, IP67, IP68, IP69
 Plugging cycles ≥ 100
