7789802010 - 1m Pre-assembled LiYCY Cable with SUB-D 50P & HE10 40P Connectors

*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color

Description:

Elevate your digital connectivity with this pre-assembled LiYCY cable Featuring a cross-sectional area of 025 mm², it adheres to RoHS regulations for eco-friendly use This versatile cable is fitted with connectors on both ends: a female SUB-D 50P interface and an HE10 40P connector, facilitating a seamless connection With an outer diameter of 134 mm (± 1 mm tolerance), it’s built to endure a wide operating temperature range from -10 to 50 °C and can be safely stored between -10 and 60 °C.

It supports a maximum current strength of 1 A and is capable of carrying a total current of up to 3 A, boasting a low resistance of less than 80 mΩ/m Additionally, it has a robust high voltage testing capacity of 1 KV for one second This cable is an excellent choice for a variety of digital signal applications, ensuring reliable performance and connectivity.

Features and Benefits:

•RoHS compliant.

•Designed for digital signals.

•High voltage test capability.

•Suitable for various temperature ranges.

•Low resistance.

•Pre-assembled configuration.

Specifications:
