Product Information

Description:

Introducing a top-tier dragline cable tailored for PROFINET systems, featuring M8 D-code connections that are safeguarded with IP67 rating at both pin and socket ends This cable adheres to Cat5 and Cat5e standards, ensuring reliable performance With an impressive length of 30 meters, it weighs 1,851 grams, making it suitable for a wide range of temperatures during storage, operation, and installation.

Perfect for robust industrial environments.

Features and Benefits:

•Compatible with Cat.5 (ISO/IEC 11801) / Cat.5e (TIA T568-B).

•IP67 rated connectors providing protection against dust and water.

•Halogen-free according to IEC 60754-2.

•Very good abrasion resistance.

•Mechanical resilience with 3 million bending cycles.

Specifications:

Cable Length	30 m
Diameter of inner sheathing	3.9 mm
Sheath diameter, max.	6.7 mm
Sheath diameter, min.	6.3 mm
Operating voltage (UL rating)	600 V
Signal propagation time	5.3 ns/m
Category	Cat.5 (ISO/IEC 11801) / Cat.5e (TIA T568-B)
Characteristic impedance	100 ± 15 Ω at 1–100 MHz
Loop resistance	120 Ω/km
Capacity at 1 kHz	52 nF/km
Transfer impedance	20 mΩ/m at 10 MHz
Resistance to spread of flame	in accordance with IEC 60332-1
Min. bending radius, once only	5 x cable diameter
Min. bending radius, repetitive	7.5 x cable diameter
Pulling force	≤ 150 N
Fire propagation	No
UV-resistant	Yes
Silicone-free	Yes
Resistance to oils	in accordance with IEC 60811-2-1
