2455200500 - 5m Unshielded Sensor/Actuator Cable with Angled Socket

2455200500 - 5m Unshielded Sensor/Actuator Cable with Angled Socket

SKU: SKU: 2455200500   Download PDF

Select a Variant:
  • 2455200500 - 5m Unshielded Sensor/Actuator Cable with Angled Socket
Qty:
Regular price Now $53.01   Web pricing policy
Regular price BEFORE   $0.00 Sale price Now $53.01 Web pricing policy
Sold out
Shipping calculated at checkout.
IN STOCK
Shipping Available
Free shipping on orders above $1000. *Wires and cables only.
View full details
Product Information

Description:

Discover the SAIL-M12BW-L-50PGR sensor/actuator product, an exceptional choice for your connectivity needs This model features a 5-meter length and boasts an angled socket design, providing flexibility and ease of use Its unshielded construction ensures reliability, while the PUR sheath material guarantees durability and is halogen-free Additionally, this product is RoHS compliant, meeting industry standards for safety and environmental protection.

Perfect for various applications, it's a reliable addition to your setup.

Features and Benefits:

    •Number of poles: 5.

    •LED: No.

    •Sheath material: PUR.

    •Bending cycles: 10 million.

    •Bending radius (moving): 7.5 times the cable diameter.

    •Bending radius (stationary): 4 times the cable diameter.

    •Cord color options: brown, white, blue, black, pink.

    •Nominal current: 16A.

    •Nominal voltage: 50V.

    •Protection degree: IP65/IP67 when screwed in.

    •Connection thread: M12.

Specifications:

 Cable length 5m
 Outer diameter 8 mm ± 0.2 mm
 Core cross-section 1.5 mm²
 Insulation resistance 10^8 Ω
 Temperature range (moving) -30...80 °C
 Temperature range (stationary) -40...80 °C
 Plugging cycles ≤ 100
 Coding L-coded
 Housing main material PUR
 Certificate no. (cULus) E257571
