16 AWG 2 Conductor Foil Shielded CMR Riser SR-PVC Insulation 300V Security Cable

• Size: 16 AWG
• Number of Conductors: 4
• Conductor Stranding: 19/.0117
• Nominal Insulation Thickness: 0.009 inches
• Nominal Jacket Thickness: 0.015 inches
• Outside Diameter: 0.219 inches

Color:

Gray

Applications:

Access control, Video Surveillance/CCTV, Intercom, Security, Home THeater and Burglar Alarms.

Compliances:

- CL3R Cable: NEC Article 725 Type CL3R Cable (UL: 75°C, 150V)
- CMR Cable: NEC Article 800 Type CMR Cable (UL: 75°C, 300V)

Conductor:

Stranded, bare copper to ASTM B3, B8, and B286

Insulation:

Premium-grade, color-coded S-R-PVC

Shield:

- Overall polyester supported aluminum foil
- Stranded tinned copper drain wire

Jacket:

Gray Premium-grade Polyvinyl Chloride (PVC)
-20°C to +75°C Includes ripcord
