1403060000 - Black PA 66 GF 30 Cable Clamp, 4-13.5mm, Snap-On
1403060000 - Black PA 66 GF 30 Cable Clamp, 4-13.5mm, Snap-On
SKU: SKU: 1403060000 Download PDF
- 1403060000 - Black PA 66 GF 30 Cable Clamp, 4-13.5mm, Snap-On
- 1403060000 - Black PA 66 GF 30 Cable Clamp, 4-13.5mm, Snap-On
Couldn't load pickup availability
*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color
Description:
Introducing the KLBUE 4-135 RC TS27, crafted from durable PA 66 GF 30 material, specifically engineered for shield connections This product features an efficient snap-on mounting system for easy installation, making setup a breeze It complies with RoHS regulations, ensuring it meets stringent environmental standards Capable of securely clamping cables with diameters between 4 mm and 135 mm, it operates at a rated voltage of 230 V and accommodates a maximum cross-section of 10 mm².
Available in a classic black finish, this item also boasts a UL 94 flammability rating of V-0, combining safety with functionality.
Features and Benefits:
•Direct mounting with snap-on type.
•Environmentally compliant with RoHS exemption.
•End cover plate not required.
•Explosion-tested version not applicable.
Specifications:
| Depth | 55.6 mm |
| Height | 67.5 mm |
| Width | 37.5 mm |
| Storage temperature | -25 °C...55 °C |
| Ambient temperature | -5 °C…40 °C |
| Continuous operating temp., min. | -25 °C |
| Continuous operating temp., max. | 105 °C |
| Cable diameter, max. | 13.5 mm |
| Cable diameter, min. | 4 mm |
| Connection cross-section, stranded, max. | 13.5 mm² |
| Connection cross-section, stranded, min. | 4 mm² |
| Stripping length | 24.3 mm |
| Type of connection | Spring connection |
| Rated cross-section | 10 mm² |
| Rated voltage | 230 V |
| Material | PA 66 GF 30 |
| ETIM classifications | EC002020 |
| ECLASS classifications | 27-14-11-50 |
