1211080111 - 11.1m PROFINET Dragline Cable, M12 D-Code, IP67/RJ45 IP20

1211080111 - 11.1m PROFINET Dragline Cable, M12 D-Code, IP67/RJ45 IP20

SKU: 1211080111   Download PDF

Select a Variant:
  • 1211080111 - 11.1m PROFINET Dragline Cable, M12 D-Code, IP67/RJ45 IP20
Qty:
Now $108.19   Web pricing policy
BEFORE   $0.00 Now $108.19 Web pricing policy
Sold out
Shipping calculated at checkout.
IN STOCK
Shipping Available
Free shipping on orders above $1000. *Wires and cables only.
View full details
Product Information Resources Reviews
Product Information

Description:

Introducing a top-of-the-line dragline cable, specifically engineered for PROFINET applications and compliant with stringent ROHS regulations This cable boasts a straight M12 D-code socket rated at IP 67, ensuring robust protection against dust and water Additionally, it features an RJ45 connector with an IP 20 rating Adhering to both Cat5 and Cat5e standards as outlined by ISO/IEC 11801 and TIA T568-B, this cable is constructed from durable PUR material and measures an impressive 11.

1 meters in length, making it a reliable choice for your connectivity needs.

Features and Benefits:

    •Compliant with ROHS and has exemptions.

    •Suitable for various temperature ranges including storage, operating, and installation.

    •Provides protection against environmental factors with its robust design.

    •Very good abrasion resistance and UV-resistant.

    •Silicone-free materials used in construction.

    •Used in industrial communication networks.

    •Applicable in environments requiring robust and reliable connections.

Specifications:

 Length 11.1 m
 Diameter of inner sheathing 3.9 mm
 Sheath diameter, max 6.7 mm
 Sheath diameter, min 6.3 mm
 Loop resistance 120 Ω/km
 Operating voltage (UL rating) 600 V
 Signal propagation time 5.3 ns/m
 Capacity at 1 kHz 52 nF/km
 Characteristic impedance 100 ± 15 Ω at 1–100 MHz
 Delay skew 40 ns/100m
 Minimum bending radius, once only 5 x cable diameter
 Minimum bending radius, repetitive 7.5 x cable diameter
 Electrical standard Cat.5 (ISO/IEC 11801) / Cat.5e (TIA T568-B)
 Sheathing material thickness 0.9 mm
 Filler As central element
 Wire material Stranded tin-plated copper wire
 Insulation PE
 No. of wires 4
 Wire core insulation thickness 0.38 mm
