1211080084 - 8.4m PROFINET Dragline Cable with M12 D-Code Socket

SKU: SKU: 1211080084 Download PDF

Select a Variant:

1211080084 - 8.4m PROFINET Dragline Cable with M12 D-Code Socket

SET THE QTY:

Now $94.27 Web pricing policy

~~BEFORE $0.00~~ Now $94.27 Web pricing policy

Sold out

Shipping calculated at checkout.

IN STOCK
Shipping Available

Free shipping on orders above $1000. *Wires and cables only.

View full details

Product Information Resources Reviews

Product Information

Description:

Enhance your connectivity with this robust dragline cable designed for PROFINET applications Featuring an IP 67 rated M12 D-code straight socket for optimal protection, it also includes an IP 20 rated RJ45 plug This cable meets the Category 5 standards as outlined in ISO/IEC 11801 and TIA T568-B, ensuring reliable communication Constructed from durable PUR, it stretches an impressive 84 meters, making it ideal for various setups and environments.

Features and Benefits:

•Complies with RoHS regulations.

•Excellent abrasion resistance.

•Halogen-free according to IEC 60754-2.

•UV-resistant.

•Very good resistance to oils.

•Silicone-free.

Specifications:

Length	8.4 m
Net weight	500 g
Storage temperature	-50 °C...70 °C
Operating temperature	-40 °C...70 °C
Installation temperature	-20 °C...60 °C
Category	Cat.5 (ISO/IEC 11801) / Cat.5e (TIA T568-B)
Characteristic impedance	100 ± 15 Ω at 1–100 MHz
Operating voltage (UL rating)	600 V
Mechanical properties	{'Bending cycles': '3 Mio', 'Min. bending radius, once only': '5 x cable diameter', 'Resistance to spread of flame': 'in accordance with IEC 60332-1'}
