2569000000 - 120W Switch-Mode Power Supply, 12V Efficiency 90%

*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color

Description:

Introducing the PRO TOP1, a robust switch-mode power supply unit delivering a powerful 120W output tailored for 12V uses With an impressive efficiency rating of 90%, this unit is designed for optimal performance It supports an AC input voltage range from 85 to 277V, making it versatile for different settings Additionally, the PRO TOP1 meets RoHS compliance and has achieved multiple approvals, including cULus certification.

With physical dimensions of 125mm (depth) x 130mm (height) x 35mm (width) and a weight of 850g, this compact power supply is both efficient and reliable for your power needs.

Features and Benefits:

•Input voltage range of 85 to 277 V AC.

•Nominal output current of 10 A at 60 °C.

•Multiple of the rated current at 400% under peak load.

•High efficiency at 90%.

•Protection against inverse voltage.

•Surge protection via varistor.

•Metal housing that is corrosion resistant.

•Connection system features PUSH IN with actuator.

Specifications:
