2627630000 - Compact 20A DC/DC Converter, 125mm Depth, Rugged Metal Design

*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color

Description:

Introducing the PRO TOPDC 24V/24V 20A DC/DC converter, engineered for high-efficiency power conversion This compact unit measures 125 mm deep, 130 mm tall, and 75 mm wide, with a weight of approximately 1,746 g It operates seamlessly in a temperature range of -25 °C to +70 °C, making it versatile for various applications With an extensive input voltage capacity of 14 V to 312 V, it delivers a stable 24 V DC output at a maximum current of 20 A.

The sturdy metal casing ensures durability and compliance with environmental standards Additionally, the converter includes features like inrush current limitation, the ability for parallel connections, and multiple protection measures against overloads and inversions, guaranteeing reliable performance.

Features and Benefits:

•RoHS compliant.

•High efficiency of 91%.

•Operating time minimum of 1,018,000 hours.

•Short-circuit protection.

•Protection degree IP20.

•Multiple output connections up to 10 units.

•LED indicators for operational status.

Specifications:
