2080600000 - 8A Electronic Load Monitor, 125mm Height

*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color

Description:

Introducing the AMG ELM-8F, an efficient solution for electronic load monitoring with a current rating of 8 A and a voltage of 24 V DC This product proudly complies with RoHS regulations and showcases its quality with certification number E258476 for cULus With compact dimensions of 122 mm in width, 125 mm in height, and a depth of 965 mm, it is lightweight at only 57 g Ideal for reliable load monitoring in various applications.

Features and Benefits:

•Current consumption during full load is approximately +30 mA.

•Provides surge protection with a suppressor diode.

•Flexible connection system using PUSH IN terminals.

•Adjustable rated current capability is not included.

•Operates over a range of temperatures from -25 °C to 70 °C.

•Offers a maximum capacitive load of 15,000 µF.

•Activation times for function keys are less than 3 seconds.

Specifications:
