1164730000 - OMNIMATE CH20M 45mm Plastic Front Element, IP20 Rated (Pack of 30)

*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color

Description:

Introducing the OMNIMATE Housing series front element CH20M, expertly crafted with a width of 45 mm This durable plastic component meets RoHS compliance standards fully, ensuring it is environmentally friendly It functions efficiently in a wide ambient temperature range of -25 °C to 85 °C and can withstand operating temperatures from -40 °C to 120 °C With an IP20 protection rating upon installation, it is designed for use in environments with humidity levels between 5% and 93%, preventing condensation build-up.

Moreover, it adheres to the UL 94 flammability rating of V-0, ensuring safety and reliability in diverse conditions.

Features and Benefits:

•Graphite grey color.

•Not designed for flip cover mounting.

•No encapsulation option.

•Integratable marker is not available.

•Customer specific cutouts and labeling are possible.

•Supports laser processing and milling.

Specifications:
