1155900000 - Black 5-Pole PCB Connector with Solder Flange, 1.5mm Pins (Pack of 300)

1155900000 - Black 5-Pole PCB Connector with Solder Flange, 1.5mm Pins (Pack of 300)

SKU: 1155900000   Download PDF

Select a Variant:
  • 1155900000 - Black 5-Pole PCB Connector with Solder Flange, 1.5mm Pins (Pack of 300)
Qty:
Now $3,109.58   Web pricing policy
BEFORE   $0.00 Now $3,109.58 Web pricing policy
Sold out
Shipping calculated at checkout.
IN STOCK
Shipping Available
Free shipping on orders above $1000. *Wires and cables only.
View full details
Product Information Resources Reviews
Product Information

Description:

Discover the versatility of this PCB plug-in connector, specifically engineered for the CH20M12-67 model This connector features a bus-contact block with a solder flange, ideal for THT or THR soldering It boasts five poles configured at a 180° angle, along with solder pin lengths of 15 mm Finished with a gold plating, this connector comes in an elegant black color, making it both functional and stylish for your electronic applications.

Features and Benefits:

    •Gold-plated contact surface.

    •Tape packaging.

    •RoHS compliant without exemptions.

    •Operating temperature range from -50 °C to 100 °C.

    •Storage temperature range from -40 °C to 70 °C.

    •Protection degree IP20 when installed.

Specifications:

 Rated voltage acc. to IEC 160 V
 Rated voltage under UL 300 V / 5 A
 Depth 16.3 mm
 Height 24 mm
 Width 7.4 mm
 Moisture Level (MSL) 1
 Insulating material LCP
 Insulation resistance ≥ 10^8 Ω
 Clearance, min. 2.3 mm
 Creepage distance, min. 3.2 mm
 Basic material Plastic
 Insulating material group IIIa
 Comparative Tracking Index (CTI) 175 ≤ CTI <400
 Surface finish gold
