1086110000 - 5.00mm 90° PCB Female Connector, 400V/10A Rated (Pack of 108)

1086110000 - 5.00mm 90° PCB Female Connector, 400V/10A Rated (Pack of 108)

SKU: 1086110000   Download PDF

Select a Variant:
  • 1086110000 - 5.00mm 90° PCB Female Connector, 400V/10A Rated (Pack of 108)
Qty:
Now $394.79   Web pricing policy
BEFORE   $0.00 Now $394.79 Web pricing policy
Sold out
Shipping calculated at checkout.
IN STOCK
Shipping Available
Free shipping on orders above $1000. *Wires and cables only.
View full details
Product Information Resources Reviews
Product Information

Description:

Introducing a versatile PCB plug-in connector designed for seamless integration with a 90° clamping yoke connection This female connector features a pitch of 500 mm and is fully compatible with printed circuit boards 51, 52, and 53 It meets IEC specifications for safety with ratings of 400 V / 10 A and UL ratings of 300 V / 10 A, accommodating a range of wire sizes from 02 to 25 mm², or AWG 26 to AWG 12.

Whether for professional or personal projects, this connector ensures reliable performance and secure connections.

Features and Benefits:

    •Clamping yoke connection method.

    •Three poles and touch-safe protection.

    •IP20 protection degree while plugged.

Specifications:

 Depth 30.6 mm
 Height 29 mm
 Width 17.4 mm
 Length 14.6 mm
 Net weight 2 g
 Pitch in mm 5 mm
 Number of poles 3
 Rated cross-section 2.5 mm²
 Tightening torque, min. 0.4 Nm
 Tightening torque, max. 0.6 Nm
 Material PA 66 GF 30
 Insulating material group I
 UL 94 flammability rating V-0
 Storage temperature, min. -40 °C
 Storage temperature, max. 70 °C
 Operating temperature, min. -25 °C
 Operating temperature, max. 120 °C
