1069610000 - 5.00mm Right-Angle Male PCB Connector, 4 Poles 90° (Pack of 130)

SKU: SKU: 1069610000 Download PDF

Select a Variant:

1069610000 - 5.00mm Right-Angle Male PCB Connector, 4 Poles 90° (Pack of 130)

SET THE QTY:

Now $342.61 Web pricing policy

~~BEFORE $0.00~~ Now $342.61 Web pricing policy

Sold out

Shipping calculated at checkout.

IN STOCK
Shipping Available

Free shipping on orders above $1000. *Wires and cables only.

View full details

Product Information Resources Reviews

Product Information

Description:

Introducing the SHL-SMT 500/04GR 42RL right-angle male header PCB connector, designed for reliable THT/THR solder connections With a pitch of 500 mm, this connector supports 4 poles positioned at a 90° angle Each solder pin is 42 mm long and features a tinned finish for enhanced conductivity Ideal for a range of applications, this connector also complies with RoHS environmental standards, ensuring safety and sustainability in your projects.

Features and Benefits:

•UL File Number: E60693.

•Rated for IEC: 400 V.

•Rated current: 9 A to 10 A depending on temperature.

•Protection degree: IP20.

•Can be coded for specific applications.

•Suitable for PCB connections in electronic devices.

Specifications:

Depth	27.8 mm
Height	14.4 mm
Width	20.6 mm
Insulating material	LCP
Number of poles	4
Rated voltage	{'Surge voltage class II/2': '400 V', 'Surge voltage class III/2': '320 V', 'Surge voltage class III/3': '250 V'}
Rated impulse voltage	{'Surge voltage class II/2': '4 kV', 'Surge voltage class III/2': '4 kV', 'Surge voltage class III/3': '4 kV'}
Operating temperature	{'Minimum': '-40 °C', 'Maximum': '120 °C'}
Storage temperature	{'Minimum': '-40 °C', 'Maximum': '70 °C'}
Moisture Level (MSL)	1
UL 94 flammability rating	V-0
Wire cross-section	{'Minimum AWG': '26', 'Maximum AWG': '12'}
Volume resistance	≤5 mΩ
