1909520000 - M25 Nickel-Plated Brass Cable Gland, IP68/IP69K Rated (Pack of 25)

*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color

Description:

Introducing the VG EMV GEN 1, a robust EMC cable gland engineered for superior clamping efficiency This model features straight cable glands with an M25 size designation, compatible with outer diameters between 11 mm and 17 mm It boasts IP68 certification, capable of withstanding pressure up to 5 bars for 30 minutes, as well as IP69K rating for thorough protection Crafted from brass and finished with a nickel plating, this cable gland ensures long-lasting performance in demanding environments.

Features and Benefits:

•Made from brass and nickel-plated.

•Suitable for outer cable diameters of 11 mm to 17 mm.

•IP68 rated for water and dust protection up to 5 bars (30 min.).

•IP69K rated for pressure and high-temperature washdown.

•Clamp insert made from polyamide.

•Operating temperature range from -40 °C to 100 °C.

Specifications:
