1736260000 - Neoprene Sealing Ring M32, 42mm Diameter, RoHS Compliant (Pack of 50)

1736260000 - Neoprene Sealing Ring M32, 42mm Diameter, RoHS Compliant (Pack of 50)

SKU: SKU: 1736260000 Download PDF

Variant:
  • 1736260000 - Neoprene Sealing Ring M32, 42mm Diameter, RoHS Compliant (Pack of 50)
Regular price Now $69.01
Regular price BEFORE   $0.00 Sale price Now $69.01
Sold out
IN STOCK
Shipping Available
Free shipping on orders above $1000.* Only on standard purchases of cables and wires.
View full details
Product Information

*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color

Description:

Introducing the GWDR M32-NP, a reliable sealing component featuring a neoprene flat gasket tailored for M 32 applications Crafted from neoprene, this item meets RoHS standards, ensuring it is environmentally compliant The sealing ring measures 42 mm in diameter and has an M 32 internal thread, with a thickness of 15 mm Designed to withstand extreme temperatures, it operates effectively between -40 °C and 100 °C, making it an excellent choice for various sealing requirements.

Features and Benefits:

    •Compliant with RoHS regulations.

    •Manufactured from neoprene.

    •Suitable for M 32 cable applications.

    •Operates in a wide temperature range from -40 °C to 100 °C.

Specifications:

 Basic material Neoprene
 Cable gland M 32
 Diameter of sealing ring 42 mm
 External thread M 32
 Halogen Yes
 Inside diameter D2 32 mm
 Internal thread M 32
 Number of wires 1
 O.D. 42 mm
 Operating temperature range, max. 100 °C
 Operating temperature range, min. -40 °C
 Pitch of thread 1.5 mm
 Sealing Neoprene
 Silicone No
 Thickness 1.5 mm
 ETIM 6.0 EC001181
 ETIM 7.0 EC001181
 ETIM 8.0 EC001181
 ETIM 9.0 EC001181
 ETIM 10.0 EC001181
 ECLASS 9.0 27-43-03-19
 ECLASS 9.1 27-14-44-90
 ECLASS 10.0 27-43-03-19
 ECLASS 11.0 27-43-03-19
 ECLASS 12.0 27-43-03-19
 ECLASS 13.0 27-43-03-19
 ECLASS 14.0 27-43-03-19
 ECLASS 15.0 27-43-03-19
