Description:
Introducing the MPS 7S/02 S TN B B female plug PCB connector, engineered for optimal performance with a pin pitch of 750 mm and two poles This connector meets RoHS standards and UL certifications, guaranteeing its reliability for a broad range of electrical applications Built to handle significant voltage and current ratings, it’s a dependable choice for your electrical systems Each connector measures 35 mm in depth, 15.
5 mm in height, and 133 mm in width Additionally, it operates effectively across a wide temperature spectrum while maintaining compliance without exceptions Each order comes neatly packaged in boxes for convenience.
Features and Benefits:
•Touch-safe protection against finger touch.
•Field connection type.
•SNAP IN wire connection method.
•IP20 protection degree.
•Safe for usage in ambient temperatures ranging from -50 °C to 125 °C.
•IEC and UL approved.
•Materials include PBT GF insulating material and Cu-alloy contacts.
Specifications:
| IEC Voltage Rating | 1000 V / 34.6 A / 0.5 - 4 mm² |
| UL Voltage Rating | 600 V / 18.5 A / AWG 20 - AWG 12 |
| Size | 35 mm depth, 15.5 mm height, 13.3 mm width |
| Pitch | 7.5 mm |
| Number of Poles | 2 |
| Stripping Length | 9 mm |
| Plugging Cycles | 25 |
| Material | Cu-alloy, with a tinned contact surface |
| Storage Temperature | -25 °C to 55 °C |
| Operating Temperature | -50 °C to 125 °C |
| Flammability Rating | UL 94 V-0 |
| Conventional Current Rating | 18.5 A |
