0625220000 - 12-Connection 4mm² Terminal Strip, Yellow, 32A, 400V (Pack of 50)
0625220000 - 12-Connection 4mm² Terminal Strip, Yellow, 32A, 400V (Pack of 50)
SKU: SKU: 0625220000 Download PDF
- 0625220000 - 12-Connection 4mm² Terminal Strip, Yellow, 32A, 400V (Pack of 50)
- 0625220000 - 12-Connection 4mm² Terminal Strip, Yellow, 32A, 400V (Pack of 50)
Couldn't load pickup availability
*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color
Description:
Upgrade your electrical connections with this versatile terminal strip Available in a vibrant medium yellow, it accommodates both single and multi-pole configurations This strip supports a rated cross-section of 4 mm² and is engineered to handle a nominal current of 32 A, along with a voltage capacity of 400 V With 12 connections arranged in a single level, it offers reliable performance for your wiring needs.
Features and Benefits:
•Complies with RoHS regulations without exemption.
•Direct mounting installation.
•Explosion-tested version not required.
•Required end cover plate is not necessary.
Specifications:
| Depth | 20 mm |
| Height | 22 mm |
| Width | 52 mm |
| Rated voltage | 400 V |
| Rated cross-section | 4 mm² |
| Nominal current | 32 A |
| Number of poles | 6 |
| Number of connections | 12 |
| Storage temperature | -25 °C...55 °C |
| Ambient temperature | -5 °C…40 °C |
| Continuous operating temp., min. | -60 °C |
| Continuous operating temp., max. | 130 °C |
| Clamping screw | M 3 |
| Tightening torque, max. | 0.6 Nm |
| Tightening torque, min. | 0.5 Nm |
| UL rating data - Certificate No. | E60693 |
| Wire connection cross section AWG, max. | AWG 12 |
| Wire connection cross section AWG, min. | AWG 22 |
| Environmental Compliance | Compliant without exemption |
