0479720000 - 12-Connection Yellow Terminal Strip for 2.5 mm² Conductors (Pack of 100)
0479720000 - 12-Connection Yellow Terminal Strip for 2.5 mm² Conductors (Pack of 100)
SKU: SKU: 0479720000 Download PDF
- 0479720000 - 12-Connection Yellow Terminal Strip for 2.5 mm² Conductors (Pack of 100)
- 0479720000 - 12-Connection Yellow Terminal Strip for 2.5 mm² Conductors (Pack of 100)
Couldn't load pickup availability
*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color
Description:
Optimize your wiring solutions with this versatile terminal strip that supports both single and multi-pole connections through flat-blade terminals Crafted in a striking medium yellow, it is designed to accommodate 25 mm² conductors, offering reliable performance with a current rating of 6 A and a voltage capacity of 400 V This efficient terminal strip provides 12 customizable connection points and is organized within a single level for ease of use.
Features and Benefits:
•Flat-blade connection.
•Compatible with mounting rails.
•No end cover plate is necessary.
•Direct mounting installation.
Specifications:
| Depth | 12.5 mm |
| Height | 6,800 mm |
| Width | 113 mm |
| Net weight | 17.846 g |
| Storage temperature | -25 °C...55 °C |
| Ambient temperature | -5 °C…40 °C |
| Continuous operating temperature, min | -60 °C |
| Continuous operating temperature, max | 130 °C |
| UL File Number | E60693 |
| Number of connections | 12 |
| Rated cross-section | 2.5 mm² |
| Rated voltage | 400 V |
| Nominal current | 6 A |
| Volume resistance | 1.33 mΩ |
| Rated impulse withstand voltage | 6 kV |
| Pollution severity | 3 |
