0274120000 - 10-Connection Yellow Terminal Strip, 2.5 mm², 24 A, 400 V (Pack of 50)
0274120000 - 10-Connection Yellow Terminal Strip, 2.5 mm², 24 A, 400 V (Pack of 50)
SKU: SKU: 0274120000 Download PDF
- 0274120000 - 10-Connection Yellow Terminal Strip, 2.5 mm², 24 A, 400 V (Pack of 50)
- 0274120000 - 10-Connection Yellow Terminal Strip, 2.5 mm², 24 A, 400 V (Pack of 50)
Couldn't load pickup availability
*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color
Description:
Enhance your electrical projects with this versatile terminal strip, designed for both single and multi-pole applications Featuring a vibrant medium yellow color, it offers 10 screw connections and accommodates a wire cross-section of 25 mm² With a maximum current rating of 24 A and voltage capacity of 400 V, it’s an essential choice for reliable performance This terminal strip is structured in a single level, making it a compact and functional solution for your needs.
Features and Benefits:
•Compliant with RoHS standards without exemptions.
•Installation is straightforward, designed for direct mounting.
•Explosion-tested version is not available.
Specifications:
| Depth | 16.1 mm |
| Height | 15 mm |
| Width | 45 mm |
| Net weight | 16.28 g |
| Storage temperature | -25 °C...55 °C |
| Ambient temperature | -5 °C…40 °C |
| Continuous operating temp., min. | -60 °C |
| Continuous operating temp., max. | 130 °C |
| Number of connections | 10 |
| Rated voltage | 400 V |
| Nominal current | 24 A |
| Rated DC voltage | 400 V |
| Volume resistance according to IEC 60947-7-x | 1.33 mΩ |
| Rated impulse withstand voltage | 6 kV |
| Power loss in accordance with IEC 60947-7-x | 0.77 W |
| Pollution severity | 3 |
| Wire connection cross section AWG, max. | AWG 12 |
| Wire connection cross section AWG, min. | AWG 22 |
| System specifications - Number of levels | 1 |
| System specifications - Mounting rail | Mounting plate |
| Standard compliance | IEC 60947-7-1 |
