0241860000 - 24 Connection Yellow Terminal Strip, 1.5mm², 24A (Pack of 100)
0241860000 - 24 Connection Yellow Terminal Strip, 1.5mm², 24A (Pack of 100)
SKU: SKU: 0241860000 Download PDF
- 0241860000 - 24 Connection Yellow Terminal Strip, 1.5mm², 24A (Pack of 100)
- 0241860000 - 24 Connection Yellow Terminal Strip, 1.5mm², 24A (Pack of 100)
Couldn't load pickup availability
*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color
Description:
Discover the versatility of this terminal strip, designed for both single and multi-pole applications Finished in a vibrant medium yellow, it offers screw connections for secure fittings With a cross-section of 15 mm², it accommodates a maximum current of 24 A and is rated for voltages up to 125 V Featuring 24 connections arranged in a single level, this product is the perfect solution for your electrical needs.
Features and Benefits:
•RoHS compliant without exemption.
•Direct mounting installation.
•Explosion-tested version: No.
•End cover plate not required.
Specifications:
| Depth | 6 mm |
| Height | 1,350 mm |
| Width | 88.5 mm |
| Storage Temperature | -25 °C to 55 °C |
| Ambient Temperature | -5 °C to 40 °C |
| Continuous Operating Temperature, Min | -60 °C |
| Continuous Operating Temperature, Max | 130 °C |
| Basic Material | KrG |
| UL 94 Flammability Rating | 5VA |
| Number of Connections | 24 |
| Rated Cross-section | 1.5 mm² |
| Rated Voltage | 125 V |
| Rated DC Voltage | 125 V |
| Nominal Current | 24 A |
| Current at Maximum Wires | 17.5 A |
| Volume Resistance According to IEC 60947-7-x | 1.83 mΩ |
| Rated Impulse Withstand Voltage | 1.5 kV |
| Power Loss in Accordance with IEC 60947-7-x | 0.56 W |
