0624720000 - 4 Connection Terminal Strip, 32A, Yellow Design (Pack of 100)
0624720000 - 4 Connection Terminal Strip, 32A, Yellow Design (Pack of 100)
SKU: SKU: 0624720000 Download PDF
- 0624720000 - 4 Connection Terminal Strip, 32A, Yellow Design (Pack of 100)
- 0624720000 - 4 Connection Terminal Strip, 32A, Yellow Design (Pack of 100)
Couldn't load pickup availability
*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color
Description:
Introducing the BK 2 CRN terminal strip, engineered for both single and multi-pole connections This robust component boasts a stylish medium yellow design and features a screw connection system It supports a rated connection of 4 mm² and accommodates a maximum current of 32 A, with a voltage rating of 400 V With the capability to manage 4 connections, this terminal strip ensures reliable performance across a variety of temperature ranges, making it a versatile choice for your electrical needs.
Features and Benefits:
•Medium yellow color.
•Rated voltage of 400 V.
•Maximum current rating of 32 A.
•Screw connection type.
•Designed for direct mounting.
•UL compliant with certificate number E60693.
•RoHS compliant without exemption.
•Explosion-tested version is not required.
Specifications:
| Depth | 20 mm |
| Height | 22 mm |
| Width | 20 mm |
| Storage temperature | -25 °C…55 °C |
| Ambient temperature | -5 °C…40 °C |
| Continuous operating temp., min. | -60 °C |
| Continuous operating temp., max. | 130 °C |
| Basic material | KrG |
| UL 94 flammability rating | V-0 |
| Number of connections | 4 |
| Clamping range, max. | 4 mm² |
| Clamping range, min. | 0.33 mm² |
| Tightening torque, max. | 0.6 Nm |
| Tightening torque, min. | 0.5 Nm |
| Rated cross-section | 4 mm² |
| Rated DC voltage | 400 V |
| Nominal current | 32 A |
| Rated impulse withstand voltage | 6 kV |
