2872550000 - 5mm Female PCB Connector, 3 Poles, 180° Angle (Pack of 72)

*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color

Description:

Introducing a precision-engineered female plug PCB connector, designed for optimal performance with a measurement of 500 mm This connector features three poles and a 180° angle, utilizing a reliable clamping yoke connection that supports a clamping range of up to 4 mm² It meets stringent ROHS and UL standards, making it ideal for applications requiring 400 V at 23 A, with compatible wire cross-sections ranging from 0.

2 to 4 mm² Each unit is carefully packaged in boxes to ensure safe handling and delivery, guaranteeing long-lasting reliability in various projects.

Features and Benefits:

•Compliant with international standards and norms.

•Developed with attention to IPC-A-610 'Class 2' standards.

•Available with gold-plated contact surfaces upon request.

•Provides operational efficiency with a plugging force required between 6 N and 10 N.

•Features a longer storage period of 36 months under specific humidity and temperature conditions.

Specifications:
