2827300000 - 68-Pole PCB Female Connector, 1.27mm Pitch, IDC Terminals (Pack of 10)

*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color

Description:

Discover this reliable PCB plug-in female connector, featuring a compact 127 mm pitch and 68 poles for robust connectivity Packaged securely and compliant with RoHS standards, this connector utilizes insulation displacement connection (IDC) technology with easy IDC terminal wire connections Its conductor outlet direction is versatile, supporting both 90° and 270° orientations Engineered for durability, the connector has endured testing for up to 500 plugging cycles and operates efficiently in temperatures ranging from -20 °C to 105 °C.

Crafted from high-quality LCP insulating material, it ensures long-lasting performance in various applications.

Features and Benefits:

•Compliant with RoHS standards without any exemptions.

•Insulation displacement connection method.

•Able to handle a maximum rated current of 1.65 A.

•Configured to accommodate AWG 30/1 and 30/7 wire connections.

•IP20 protection degree.

Specifications:
