2747480000 - 40-Pole 1.27mm PCB Connector, 90° Angle, RoHS Compliant (Pack of 560)

*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color

Description:

Introducing the FFH S1/40H F1 B RL, a specialized PCB plug-in connector tailored for female header arrangements This connector boasts a precision surface-mounted solder connection with a compact 127 mm pitch and is engineered with 40 poles set at a 90-degree angle Each of the poles is packaged using a reliable tape method and can handle operational voltages up to 150 V in line with UL standards Additionally, this product meets RoHS compliance and has a lightweight design, with a net weight of 4.

339 g, making it a fantastic choice for your electronic assembly needs.

Features and Benefits:

•Pitch of 1.27 mm.

•Rated current of 2.8 A.

•Transmits data at a rate of 3.125 Gbit/s.

•Can endure up to 500 plugging cycles.

•Insulating material made of LCP.

•Operates within a temperature range of -55 °C to 125 °C.

•Moisture sensitivity level of 1.

Specifications:
