2826890000 - 1.27mm Pitch Female PCB Connector, IP20, 12 Poles (Pack of 10)

*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color

Description:

Introducing the versatile PCB plug-in connector, crafted as a female connector with a compact 127 mm pitch and designed to accommodate up to 12 poles This connector employs insulation displacement connection (IDC) technology, ensuring reliable and efficient wire connections With a length of 122 mm and a lightweight of 448 grams, it's easy to integrate into various applications Complying with RoHS standards, this product is free from SVHCs in concentrations above 0.

1 wt%, making it a responsible choice for environmentally conscious projects As part of the OMNIMATE Signal series, it boasts an IP20 degree of protection The connector can handle a maximum rated current of 19 A at 20°C, ensuring robust performance, with a minimum clearance and creepage distance of 04 mm Designed for a wide operating temperature range of -20°C to 105°C, it demonstrates excellent thermal resilience.

Made from high-quality LCP for its insulation, the contacts consist of a durable copper alloy, further enhanced with nickel and gold plating for longevity and reliability in all conditions.

Features and Benefits:

•Compliant with RoHS without exemptions.

•IDC terminal for effective wire connections.

•Packaged in boxes of 10 items.

•Plugging cycles rated at 500.

•Insulation resistance of ≥ 20 MΩ.

•UL 94 flammability rating of V-0.

•Conforms to IPC-A-610 Class 2 standards.
