Description:

Ensure reliable control with this solid-state relay, engineered for control voltages between 15 V and 30 V This unit adeptly switches voltages ranging from 12 V to 275 V AC and supports a steady current of 4 A Its plug-in connection simplifies installation, making it an efficient choice for your electrical needs.

Features and Benefits:

•Compliant with RoHS regulations.

•Light blue color.

•No status indicator.

•Plug-in connection method.

•Short-circuit-proof feature is absent.

•Single normally-open contact.

•Leakage current is less than 1 mA.

Specifications:

Rated control voltage	15 V UC...30 V UC
Nominal control current	10 mA DC ±20 %
Power rating	240 mW
Rated switching voltage	12...275 V AC
Continuous current	4 A
Rated switching current	4 A
Switch-on delay	≤ 12 ms
Switch-off delay	20 ms
Voltage drop at max. load	≤ 1.1 V
Insulation coordination Rated voltage	300 V
Surge voltage category	III
Clearance and creepage distances for control side - load side	> 8 mm
Impulse withstand voltage	4 kV (1.2/50 µs)
Storage temperature	-40 °C...50 °C
Ambient temperature	-40 °C…50 °C
