9441710000 - RS 32IO 2W Interface Device with Screw Connection, 200mm Width

*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color

Description:

Introducing the RS 32IO 2W R S, a versatile interface device specifically engineered for 2-wire connections utilizing screw terminals This product meets RoHS standards and is UL approved (File Number E141197), ensuring its reliability and safety With compact dimensions of 72 mm in depth, 87 mm in height, and 200 mm in width, it weighs 32032 g, making it lightweight and easy to install The RS 32IO operates effectively in temperatures ranging from -25 to 50 °C, with a storage capacity between -40 to 60 °C.

It boasts a channel current capacity of 1 A, with a total maximum operating current of 3 A The device accommodates a rated voltage of up to 150 V UC and features a robust screw connection for the power supply along with a flexible wire connection for enhanced adaptability.

Features and Benefits:

•RoHS compliant with exemption.

•LED status display is not available.

•No disconnection feature per channel.

•Common pole polarity can be positive or negative using a jumper.

Specifications:
