9448120000 - 2-Wire Interface, 197mm x 109mm, RoHS Compliant

Description:

Introducing this advanced interface, engineered for a secure 2-wire connection utilizing a reliable screw mechanism It adheres to RoHS standards, featuring exceptions, and possesses a UL file number for validation With dimensions of 81 mm in depth, 109 mm in height, and 197 mm in width (equivalent to 3189, 4291, and 7756 inches, respectively), this unit boasts a net weight of 596 g Designed for versatility, it operates effectively within a storage temperature range of -40 to 60 °C and performs optimally at temperatures from -20 to +50 °C.

The device supports multiple types of connections and is rated for specific voltage and current parameters, making it a reliable choice for various applications.

Features and Benefits:

•LED status display per channel: no.

•Disconnection per channel: yes.

•Voltage measurement point included.

•Current-measuring test point: diameter of 4 mm.

•Power supply fuse rated at 3.15 A.

•Polarity of common pole can be determined using a jumper.

Specifications:
