9445710000 - RS Communication Interface with Screw Connection and LED Indicators

9445710000 - RS Communication Interface with Screw Connection and LED Indicators

SKU: 9445710000   Download PDF

Select a Variant:
  • 9445710000 - RS Communication Interface with Screw Connection and LED Indicators
Qty:
Now $74.50   Web pricing policy
BEFORE   $0.00 Now $74.50 Web pricing policy
Sold out
Shipping calculated at checkout.
IN STOCK
Shipping Available
Free shipping on orders above $1000. *Wires and cables only.
View full details
Product Information Resources Reviews
Product Information

Description:

Introducing the RS 16IO 1W L H S, a versatile device featuring a reliable screw connection interface specifically designed for RS communication It includes LED indicators for easy monitoring This model, identified by the order number 9445710000, adheres to RoHS standards, ensuring safe use The product operates effectively within a temperature range of -25 °C to 50 °C and can be stored in conditions between -40 °C and 60 °C, making it suitable for various environments.

Features and Benefits:

    •LED status display for each channel is green.

    •No disconnection per channel.

    •No test points available.

    •No fuses per channel.

    •LED indicating supply voltage is yellow.

    •Screw connection for both field and supply connections.

Specifications:

 Depth 72 mm
 Height 87 mm
 Width 46 mm
 Net weight 122 g
 Storage temperature -40...60 °C
 Operating temperature -25...50 °C
 Operating voltage 24 V DC ± 10%
 Max. current per channel 1 A
 Total operating current 2 A
 Rated voltage 24 V DC
 Rated current supply 2 A
 Rated current fuse supply 3.15 A
 Clamping range 0.13 to 6 mm²
 Tightening torque 0.5 to 0.6 Nm
