9448100000 - Compact Two-Wire Interface Device, 81mm x 73mm x 109mm

Description:

Introducing a versatile two-wire interface device equipped with a reliable screw connection This product is RoHS compliant and holds various approvals, falling under multiple ETIM and ECLASS categories Measuring 81 mm in depth, 109 mm in height, and 73 mm in width, it has a lightweight design at only 244 grams Designed for a temperature range of -20 to 50 °C and capable of being stored at temperatures between -40 and 60 °C, it ensures optimal performance.

With a rated supply voltage of 24 V and the ability to handle a maximum current of 3 A, this device is both practical and efficient for your needs.

Features and Benefits:

•LED status display per channel not available.

•Disconnection capability per channel.

•Voltage point of measurement is included.

•Current-measuring test point of diameter 4 mm.

•Common pole polarity can be selected as positive or negative.

Specifications:
