9445810000 - 24V DC Interface Component with LED Status Display

9445810000 - 24V DC Interface Component with LED Status Display

SKU: 9445810000   Download PDF

Select a Variant:
  • 9445810000 - 24V DC Interface Component with LED Status Display
Qty:
Now $100.85   Web pricing policy
BEFORE   $0.00 Now $100.85 Web pricing policy
Sold out
Shipping calculated at checkout.
IN STOCK
Shipping Available
Free shipping on orders above $1000. *Wires and cables only.
View full details
Product Information Resources Reviews
Product Information

Description:

Introducing a versatile interface component, this product features a secure screw connection and operates at a voltage of 24 V DC It boasts multiple ratings, including a rated current of 2 A, making it suitable for a range of applications With integrated LED status indicators that illuminate green for each channel and a yellow light for supply voltage, monitoring performance is effortless Additionally, it allows for channel disconnections as needed.

Built to meet UL standards and RoHS compliance, this product combines reliability with safety.

Features and Benefits:

    •LED status display for each channel.

    •Connections enable a flexible range of wire sizes.

    •Screw connection type for reliability.

Specifications:

 Depth 72 mm
 Height 87 mm
 Width 110 mm
 Net weight 254 g
 Operating temperature -25...50 °C
 Storage temperature -40...60 °C
 Rated voltage 24 V DC
 Rated current 2 A
 Max current per channel 1 A
 Insulation coordination According to DIN EN 50178
 Rated insulation voltage <50 V AC
 Surge voltage category III
 Pollution severity level 2
 Pulse voltage test 0.8 kV
 Insulation test voltage AC 0.35 kV
 Tightening torque 0.5 Nm - 0.6 Nm
 Connection type Screw connection
 Common pole polarity Yes
