9441700000 - 2-Wire Interface Module with Screw Connections, UL Certified

SKU: SKU: 9441700000 Download PDF

Select a Variant:

9441700000 - 2-Wire Interface Module with Screw Connections, UL Certified

SET THE QTY:

Now $98.31 Web pricing policy

~~BEFORE $0.00~~ Now $98.31 Web pricing policy

Sold out

Shipping calculated at checkout.

IN STOCK
Shipping Available

Free shipping on orders above $1000. *Wires and cables only.

View full details

Product Information Resources Reviews

Product Information

Description:

Introducing the RS 16IO 2W R S, expertly crafted for two-wire interfaces with secure screw connections This reliable component meets RoHS standards and holds a UL certification (file number E141197) With an impressive operational temperature range of -25°C to 50°C, it is designed to function effectively within defined electrical parameters, making it suitable for a variety of applications.

Features and Benefits:

•Compliant with RoHS and has UL certification.

•Operates effectively within a temperature range of -25°C to 50°C.

•Suitable for various electrical applications with a max current of 3 A.

Specifications:

Depth	72 mm
Height	87 mm
Width	123 mm
Storage temperature	-40...60 °C
Operating voltage	150 V UC
Max. current per channel	1 A
Total operating current	3 A
Rated current I	1 A
Rated voltage U N (supply)	24 V
Rated current (supply)	3 A
Rated voltage fuse U N (supply)	250 V
Rated current fuse (supply)	3.15 A
Connection (field side)	LM2N 5.08 mm
Wiring system	2-wire
Insulation coordination (EN50178)	According to DIN EN 50178
Rated insulation voltage	<150 V AC
Surge voltage category	II
Pollution severity level	2
Pulse voltage test (1,2/50μs)	1.5 kV
Insulation test voltage AC	1.1 kV
Stripping length	6 mm
Tightening torque, max.	0.6 Nm
Type of connection	Screw connection
