9445970000 - RS 32IO 3W Interface with LED, 72mm Depth, 421g

Description:

Introducing the RS 32IO 3W L H S, a versatile interface component featuring a 3-wire screw connection, perfect for a variety of applications This device is constructed with durability in mind and adheres to RoHS standards It measures 176 mm in width, 87 mm in height, and 72 mm in depth, with a total weight of 421 g The RS 32IO operates effectively within a temperature range of -25 to 50 °C and can be stored in conditions between -40 and 60 °C.

An intuitive LED display shows the status of each channel in vibrant green, complemented by a yellow LED that indicates supply voltage Each channel supports a maximum current of 1 A, allowing for a total operational current of 2 A, with a steady operating voltage of 24 V DC ± 10% This robust interface offers multiple connection options, making it an excellent choice for various control systems, ensuring reliable and efficient performance in any setup.

Features and Benefits:

•Compliant with RoHS regulations.

•LED status display for monitoring.

•Screw connection type for secure wiring.

•Designed for maximum current of 1 A per channel.

Specifications:
