9445720000 - RS 2-Wire Interface, Screw Connection, -25 to 50°C

9445720000 - RS 2-Wire Interface, Screw Connection, -25 to 50°C

SKU: 9445720000 Download PDF

Variant:
  • 9445720000 - RS 2-Wire Interface, Screw Connection, -25 to 50°C
Now $69.18
BEFORE   $0.00 Now $69.18
Sold out
Web pricing policyShipping calculated at checkout.
IN STOCK
Shipping Available
Free shipping on orders above $1000.* Only on standard purchases of cables and wires.
View full details
Product Information Resources Reviews
Product Information

*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color

Description:

Introducing a reliable RS interface tailored for 2-wire connections featuring an efficient screw connection system This product meets RoHS standards and carries UL approval under File Number E141197 It operates effectively in temperature ranges from -25 to 50 °C and can be stored in conditions as low as -40 °C and as high as 60 °C With a maximum operating voltage of 25 V AC and 50 V DC, it supports up to 1 A per channel with a combined operational current of 2 A.

The unit also includes connections perfect for both field and control sides, featuring a 20-pole plug that complies with IEC60603-13 and DIN41651 standards for enhanced connectivity.

Features and Benefits:

    •Compliant with RoHS.

    •Operating temperature from -25 to 50 °C.

    •Storage temperature from -40 to 60 °C.

    •Screw connection type.

    •LED indicator for supply voltage status.

Specifications:

 Depth 72 mm
 Height 87 mm
 Width 87 mm
 Net weight 178.64 g
 Rated current I N 1 A
 Rated voltage U N ≤ 25 V AC 50 V DC
 Rated voltage DC U N (supply) 24 V
 Rated current (supply) 2 A
 Rated current fuse (supply) 3.15 A
 Operating voltage 25 V AC / 50 V DC
 Max. current per channel 1 A
 Total operating current 2 A
 Rated insulation voltage <50 V AC
 Surge voltage category III
 Pollution severity level 2
 Pulse voltage test (1,2/50μs) 0.8 kV
 Insulation test voltage AC 0.35 kV
 Type of connection Screw connection
 Connection (field side) LP2N 5.08mm
 Connection on control side Plug-in connector in acc. with IEC60603-13 / DIN41651
 Number of poles (control side) 20-pole plug
