9448000000 - Compact 2-Wire Interface, 72mm Depth, RoHS Compliant

9448000000 - Compact 2-Wire Interface, 72mm Depth, RoHS Compliant

SKU: 9448000000 Download PDF

Variant:
  • 9448000000 - Compact 2-Wire Interface, 72mm Depth, RoHS Compliant
Now $107.39
BEFORE   $0.00 Now $107.39
Sold out
Web pricing policyShipping calculated at checkout.
IN STOCK
Shipping Available
Free shipping on orders above $1000.* Only on standard purchases of cables and wires.
View full details
Product Information Resources Reviews
Product Information

*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color

Description:

Introducing the RS 4AIO DP SD S, a robust two-wire interface designed with a secure screw connection This product meets RoHS standards and is backed by a UL certification (file number E141197) It measures 72 mm in depth (2835 inches), 87 mm in height (3425 inches), and 75 mm in width (2953 inches), making it compact for various applications Weighing 172 g, this unit operates efficiently in temperatures ranging from -20 to 50 °C and can withstand storage conditions between -40 and 60 °C.

Features and Benefits:

    •Compliant with RoHS regulations.

    •UL certified.

    •Two-wire interface.

    •Screw connection type.

    •Compact dimensions.

    •Lightweight.

Specifications:

 Depth 72 mm
 Height 87 mm
 Width 75 mm
 Net weight 172 g
 Storage temperature -40...60 °C
 Operating temperature -20...50 °C
 Rated current I N 0.5 A
 Rated voltage U N (supply) 24 V
 Rated current (supply) 3 A
 Rated voltage fuse U N (supply) 250 V
 Rated current fuse (supply) 3.15 A
 Max. current for common pole 3.15 A
 Max. current per channel 0.5 A
 Type of connection Screw connection
 Insulation voltage <50 V AC
 Surge voltage category III
 Pollution severity level 2
 Clamping range, max 6 mm²
 Clamping range, min 0.13 mm²
 Tightening torque, max 0.6 Nm
 Tightening torque, min 0.5 Nm
