8216480000 - 9-Pole D-Sub Connector for Screw Connections, 66mm Depth

*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color

Description:

Introducing the RS SD9B UNC LPK2, a robust interface connector equipped with a 9-pole female D-sub design that meets IEC 60807 and DIN 41652 standards This connector is built for secure screw connections and is UL certified, ensuring it meets various environmental regulations, including RoHS compliance With dimensions of 66 mm deep, 45 mm high, and 50 mm wide, it has a net weight of 83 grams This versatile connector operates effectively in a temperature range of -40°C to 70°C for storage and 0°C to 55°C during active use.

It supports a rated current of 15 A and functions optimally at 100 V, making it an excellent choice for a range of applications.

Features and Benefits:

•Screw connection design for easy installation.

•Compliant with RoHS regulations.

•UL listed for safety and reliability.

•Compact dimensions for space-saving applications.

Specifications:
