8155650000 - 25-Pole D-Sub Plug, RoHS & UL Approved, 66mm Depth

8155650000 - 25-Pole D-Sub Plug, RoHS & UL Approved, 66mm Depth

SKU: 8155650000   Download PDF

Select a Variant:
  • 8155650000 - 25-Pole D-Sub Plug, RoHS & UL Approved, 66mm Depth
Qty:
Now $45.88   Web pricing policy
BEFORE   $0.00 Now $45.88 Web pricing policy
Sold out
Shipping calculated at checkout.
IN STOCK
Shipping Available
Free shipping on orders above $1000. *Wires and cables only.
View full details
Product Information Resources Reviews
Product Information

Description:

Introducing the 25-pole plug specifically crafted for D-sub connectors, adhering to IEC 60807 / DIN 41652 standards This model utilizes a reliable screw connection and boasts a strong RoHS compliance approval, along with safety certification under UL (file number E141197) With dimensions of 66 mm in depth, 45 mm in height, and 86 mm in width, it has a lightweight build at 136 g Designed to perform well in a variety of environments, it can withstand storage temperatures from -40 to 70 °C and operates effectively in conditions ranging from 0 to 55 °C.

Features and Benefits:

    •RoHS compliant with exemptions.

    •UL certified.

    •Compact design suitable for various applications.

Specifications:

 Rated voltage 100 V
 Rated current 1.5 A
 Connection (field side) LPK 2H 5.08mm
 Connection on control side D-sub connectors, acc. to IEC 60807 / DIN 41652
 Design of locking system UNC 4/40
 Number of poles (control side) 25-pole plug
 Rated insulation voltage 100 V
 Surge voltage category II
 Pollution severity level 2
 Pulse voltage test (1,2/50μs) 0.8 kV
 Clamping range, max. 1.5 mm²
 Clamping range, min. 0.15 mm²
 Stripping length 6 mm
 Tightening torque, max. 0.6 Nm
 Tightening torque, min. 0.5 Nm
