8155620000 - 25-Pole Female Connector, IEC Compliant, 86mm Width

8155620000 - 25-Pole Female Connector, IEC Compliant, 86mm Width

SKU: 8155620000   Download PDF

Select a Variant:
  • 8155620000 - 25-Pole Female Connector, IEC Compliant, 86mm Width
Qty:
Now $45.88   Web pricing policy
BEFORE   $0.00 Now $45.88 Web pricing policy
Sold out
Shipping calculated at checkout.
IN STOCK
Shipping Available
Free shipping on orders above $1000. *Wires and cables only.
View full details
Product Information Resources Reviews
Product Information

Description:

Introducing the RS SD25B UNC LPK2, a robust 25-pole female connector that adheres to IEC 60807 and DIN 41652 standards Equipped with a screw connection, this connector is suitable for a wide range of applications while being both UL approved and RoHS compliant Its dimensions are compact at 86 mm wide, 45 mm high, and 66 mm deep, weighing in at 137 g This product guarantees dependable performance across various environmental conditions, with an operational temperature range of 0 to 55 °C and a storage capacity of -40 to 70 °C.

Trust in the RS SD25B to deliver reliable connectivity for your projects.

Features and Benefits:

    •Compliant with RoHS and UL standards.

    •25-pole female D-sub connector for field and control side connections.

    •Screw connection with UNC locking system.

    •Environmental compliance including REACH.

Specifications:

 Depth 66 mm
 Height 45 mm
 Width 86 mm
 Net weight 137 g
 Storage temperature -40...70 °C
 Operating temperature 0...55 °C
 Rated voltage 100 V
 Rated current I 1.5 A
 Number of poles (control side) 25-pole female
 Tightening torque, max. 0.6 Nm
 Tightening torque, min. 0.5 Nm
 Type of connection Screw connection
