8019930000 - 9-Pole D-Sub Interface Device, 80mm Depth, RoHS Certified

*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color

Description:

Introducing the RS SD9S LP3R interface device, expertly crafted with 9-pole D-sub connectors that comply with IEC 60807 / DIN 41652 standards for secure screw connections This unit meets RoHS requirements and is certified under UL File Number E141197, ensuring high quality and safety Measuring 80 mm in depth, 87 mm in height, and 40 mm in width, it has a lightweight design at just 107 g It operates effectively within a temperature range of 0 to 55 °C and can be safely stored in conditions from -40 to 70 °C.

With a rated current capacity of up to 1 A and a voltage rating of 64 V, this device comes equipped with a compliant lead and includes an earth connection for added safety.

Features and Benefits:

•RoHS compliant with exemption.

•Screw connection type.

•9-pole plug connections.

•Compliant with various ETIM and ECLASS classifications.

Specifications:
