8019900000 - 25-Pole Female Connector, 80mm Depth, RoHS Compliant

8019900000 - 25-Pole Female Connector, 80mm Depth, RoHS Compliant

SKU: 8019900000 Download PDF

Variant:
  • 8019900000 - 25-Pole Female Connector, 80mm Depth, RoHS Compliant
Now $59.60
BEFORE   $0.00 Now $59.60
Sold out
Web pricing policyShipping calculated at checkout.
IN STOCK
Shipping Available
Free shipping on orders above $1000.* Only on standard purchases of cables and wires.
View full details
Product Information Resources Reviews
Product Information

*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color

Description:

Introducing a reliable interface connector that adheres to both IEC 60807 and DIN 41652 standards This device boasts a 25-pole female screw connection, ensuring secure and efficient connectivity With dimensions of 80 mm in depth, 87 mm in height, and 60 mm in width, it is compact yet functional Weighing in at just 160 grams, it is lightweight and easy to handle This connector operates effectively within a temperature range of -40 to 70 °C for storage and from 0 to 55 °C during use.

Additionally, it is RoHS compliant and holds exemption status, making it a responsible choice for electronic applications.

Features and Benefits:

    •25-pole female connector.

    •Screw connection type.

    •RoHS compliant with exemption.

    •Environmental compliance based on REACH SVHC.

Specifications:

 Depth 80 mm
 Height 87 mm
 Width 60 mm
 Net weight 160 g
 Storage temperature -40...70 °C
 Operating temperature 0...55 °C
 Rated voltage 100 V
 Rated current per connection 1.5 A
 Number of poles (control side) 25-pole female
 Type of connection Screw connection
 Rated current I N 1 A
 Rated current I max 1 A
 Rated voltage U N 64 V
 Connection field (max clamping range) 6 mm²
 Connection field (min clamping range) 0.5 mm²
 Surge voltage category II
 Pollution severity level 2
 Stripping length 6 mm
 Tightening torque (max) 0.6 Nm
 Tightening torque (min) 0.5 Nm
