8012910000 - 20-Pole IEC Compliant Connector, 76mm Depth, RoHS Approved

*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color

Description:

Introducing the RS F20 LP3R 3/21 plug-in connector, a reliable component that adheres to IEC60603-13 and DIN41651 standards, featuring a robust 20-pole screw connection This unit complies with RoHS regulations and carries detailed approvals, including UL File Number E141197 Measuring 76 mm in depth, 87 mm in height, and 50 mm in width, it has a lightweight design at only 130 g It is capable of withstanding a wide range of temperatures, operating efficiently between 0 to 55 °C and being safe for storage from -40 to 70 °C.

Features and Benefits:

•20-pole configuration.

•Screw connection type.

•RoHS compliant with exemption.

•Includes earth connection.

•Robust design with a wide temperature range.
