8012860000 - 14-Pole Plug-In Connector, IEC60603-13, 76mm Depth

8012860000 - 14-Pole Plug-In Connector, IEC60603-13, 76mm Depth

SKU: 8012860000   Download PDF

Select a Variant:
  • 8012860000 - 14-Pole Plug-In Connector, IEC60603-13, 76mm Depth
Qty:
Now $34.18   Web pricing policy
BEFORE   $0.00 Now $34.18 Web pricing policy
Sold out
Shipping calculated at checkout.
IN STOCK
Shipping Available
Free shipping on orders above $1000. *Wires and cables only.
View full details
Product Information Resources Reviews
Product Information

Description:

Introducing the RS F14 LP3R 3/14 plug-in connector, crafted in accordance with IEC60603-13 and DIN41651 standards This robust connector boasts a 14-pole screw connection and adheres to RoHS guidelines, including the applicable exemptions With a UL certification (certificate number E141197), you can trust its quality and compliance The dimensions are practical, measuring 76 mm in depth, 87 mm in height, and 45 mm in width, while it weighs just 114 g, making it suitable for a variety of applications.

Features and Benefits:

    •RoHS compliant with exemption.

    •Suitable for various environments with a storage temperature range of -40 to 70 °C.

    •Operating temperature range from 0 to 55 °C.

    •Protection through earthing and protective earth connection with flat-blade contact.

Specifications:

 Depth 76 mm
 Height 87 mm
 Width 45 mm
 Net weight 114 g
 Rated voltage 60 V AC / 75 V DC
 Rated current I 1 A
 Connection (field side) LL3R 5.08 mm
 Number of poles (control side) 14-pole
 Insulation coordination (EN50178) According to DIN EN 50178
 Rated insulation voltage 100 V
 Surge voltage category II
 Tightening torque, max 0.6 Nm
 Tightening torque, min 0.5 Nm
