1448420000 - 230V AC Relay, 259mm, PUSH IN Connection, 4.6A Output

1448420000 - 230V AC Relay, 259mm, PUSH IN Connection, 4.6A Output

SKU: 1448420000   Download PDF

Select a Variant:
  • 1448420000 - 230V AC Relay, 259mm, PUSH IN Connection, 4.6A Output
Qty:
Now $285.30   Web pricing policy
BEFORE   $0.00 Now $285.30 Web pricing policy
Sold out
Shipping calculated at checkout.
IN STOCK
Shipping Available
Free shipping on orders above $1000. *Wires and cables only.
View full details
Product Information Resources Reviews
Product Information

Description:

Introducing the RSM-16 230VAC 1CO Z relay device, perfect for a range of applications This model boasts a convenient PUSH IN connection type for effortless installation and wiring It operates on a rated voltage of 230 V AC input with an output capability of up to 250 V AC, handling a maximum output current of 46 A With dimensions measuring 259 mm in width, 87 mm in height, and 66 mm in depth, it weighs approximately 458.

93 g Enhance your project with this reliable relay solution.

Features and Benefits:

    •LED status display per relay shows a green indication.

    •Mechanical service life rated at 10 x 10^6 switching cycles.

    •Connection options available on both the field and control sides.

Specifications:

 Depth 66 mm
 Height 87 mm
 Width 259 mm
 Storage temperature -40...60 °C
 Operating temperature -25...50 °C
 Rated voltage AC U N (input) 230 V
 Rated current I max (output) 4.6 A
 Input voltage 230 V AC ± 10%
 Input current 3.3 mA
 Relay type RCL
 Type of output Potential-free contact
 Material of contacts AgNi 90/10
 Rated voltage ≤ 250 V AC
 Max. AC continuous current 6 A
 Minimum contact current 0.1 A
 Minimum contact voltage 5 V
