1448290000 - 24V Relay Interface Module, 259mm x 87mm x 66mm, UL Listed

*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color

Description:

Introducing the compact RSM-16 24V-1CO S relay interface module, engineered for effortless installation with its screw connection design This module is UL listed and fully adheres to RoHS standards, ensuring both quality and safety Measuring 259 mm in width, 87 mm in height, and 66 mm in depth, it is lightweight at approximately 648748 grams, making it easy to integrate into various applications Built for reliability, it operates effectively within a temperature range of -25 to 50 °C and can be stored at temperatures from -40 to 60 °C.

The module boasts an LED status display to indicate the supply voltage and is designed with optimal connectivity in mind, accommodating multiple wire sizes With a rated current of 1 A at a voltage of 24 V DC, this relay interface module is perfect for a variety of operational environments while eliminating the need for relay fuses.

Features and Benefits:

•Compact design with screw connection for easy wiring.

•LED indicators for relay status and supply voltage.

•High mechanical service life rated for 30 million switching cycles.

•Wide operational temperature range from -25 to 50 °C.
